CAPACITY
| Total Capacity (cubic feet) | 5.0 |
FEATURES
| Configuration | Range with Storage Drawer |
| Element – Right Front | 8″ 2400W Temp Limiting Coil |
| Oven Features | 4-Pass Bake Element4-Pass Broil Element |
| Removable One-Piece Drip Bowls | Black Porcelain Enameled |
| Lift-Up Cooktop With Support Rods | Yes |
| Storage Drawer Features | Removable Full-Width |
| Fuel Type | Electric |
| Oven Interior | 1 Incandescent Light |
| Oven Control Features | Audible Preheat SignalAuto Oven Shut-Off with OverrideAuto Self CleanControl Lock CapabilityDelay Bake Option (Time Bake)Delay Clean OptionElectronic Clock & Kitchen TimerHi / Low BroilOven “ON” LightSelf-Clean Cool Down Time DisplaySelf-Cleaning Cycling Light |
| Cooktop Burner Type | Coil |
| Oven Rack Features | 2 Oven Racks6 Rack Positions |
| Element – Left Front | 6″ 1250W Temp Limiting Coil |
| Oven Cleaning Type | Self-Clean |
| Product Type | Free-Standing Single Oven |
| Heating Element “ON” Indicator Light | Yes |
| Cooktop Type | Coil |
| Element – Left Rear | 8″ 2400W Temp Limiting Coil |
| Sabbath Mode | Yes |
| Element – Right Rear | 6″ 1250W Temp Limiting Coil |
| Cooktop Surface | One-Piece UpsweptPorcelain-Enamel |
| Control Location | Backsplash |
| Drawer Type | Storage |
| Control Type | Digital Temperature DisplayElectronicTouchpads |
| Cooking Technology | Traditional |
APPEARANCE
| Oven Door Features | Big View Oven WindowGlass Door |
| Handle | Designer StyleStainless Steel |
| Textured Steel Side Panels | Yes |
| Control Knobs | Gloss Black |
| Color Appearance | Stainless Steel/Black |
WEIGHTS & DIMENSIONS
| Net Weight | 150.00 |
| Depth Without Handle | 26.25 |
| Oven Interior Dimensions (W x H x D) (in.) | 23.00 |
| Height to Cooking Surface (in.) | 36.00 |
| Depth with Door Open | 46.25 |
| Cabinet Width | 30.00 |
| Approximate Shipping Weight | 170.00 |
| Overall Width | 30 |
| Overall Depth | 28 3/4 |
| Overall Height | 47 |
POWER / RATINGS
| KW Rating at 240V | 11.7 |
| Bake Wattage | 2585W |
| Amp Rating at 208V | 40 |
| Broiler Wattage | 3410W |
| KW Rating at 208V | 8.8 |
| Amp Rating at 240V | 40 |
WARRANTY
| Labor Warranty | Limited 1-year entire appliance |
| Parts Warranty | Limited 1-year entire appliance |
| Warranty Notes | See written warranty for full details |
CERTIFICATIONS
| Claims & Certifications | ULCalifornia Prop 65 |
